RAM Mount Aluminum Garmin nuvi 500 Series Motorcycle Brake Clutch Mount

RAM Mount Garmin nuvi 500 Series Motorcycle Brake Mount

Click to view larger image
Mfg P/N: RAM-B-174-GA32U
SKU: RAMB174GA32

Share this item:

$30.95
List Price: ~~$36.30~~
You Save: $5.35 (15%)
Price shown in USD currency

In Stock!
Ships today!

Qty:

This item is Brand New (not refurbished), and has a Lifetime Warranty (excluding electronic or lense components)

Found a lower price? Let us know!

Canadian Customers!
See this item at gpscity.ca

JUMP TO: (Use these links to quickly jump down to a section of the page)

Accessories
Product Features

Customer Reviews
What's In The Box?

Product Videos
Product Tips

Family Tree
Alternative Units

GARMIN NUVI 500 SERIES MOTORCYCLE BRAKE MOUNT PRODUCT DETAILS

The RAM-B-174-GA32 Garmin nuvi 500 and 550 Series Motorcycle RAM Mount is a Marine Grade Aluminum Mount with a Motorcycle Brake/Clutch Reservoir Base and RAM Custom Plastic Cradle. The mount is designed with a RAM 1 inch diameter patented rubber ball and socket system that has adjustment point at the cradle and base. With a twist of the arm knob, you can move the Garmin nuvi 500 and 550 Series mount to your optimum viewing position.

Garmin GPS Mount Options:

To help ensure you have the Garmin nuvi 500 and nuvi 550 Mount you require, take a look at the list of available RAM Garmin GPS mounts on the RAM-HOL-GA32 Series of Garmin nuvi 500 and nuvi 550 Cradles and Mounts Page. Here you can select from suction cup GPS mounts, flat surface screw down GPS mounts, GPS car mounts, non skid weighted GPS mounts and more bundled with the RAM-HOL-GA32 Garmin nuvi 500 and nuvi 550 Series Cradle.

Garmin GPS Mount Cradle Design:

The RAM-HOL-GA32 RAM Mount High Strength Plastic Cradle is designed to hold the Garmin nuvi 500 and nuvi 550 Series, including the following GPS units,

Garmin nuvi 500
Garmin nuvi 550

All cables can stay connected to the unit while in the RAM cradle.

Garmin GPS Mount Cradle Plate:

The RAM-B-238 Marine Grade Aluminum Diamond Plate is designed to connected to the back of the mount cradle. The diamond plate has a 1.0 inch diameter rubber ball connected at right angles to the plate, which connects directly to the 1 inch arm socket. The cradle includes the required hardware to connect the plate to the cradle. For a layout of the hole spacing and 1.0 inch rubber ball location, take a closer look with the RAM-B-238 Design Drawings (pdf file).

Garmin GPS Mount Arm Design:

The RAM-B-201 RAM Mount Marine Grade Aluminum Dual Socket Arm is a 1 inch B size Ball Socket Arm with open socket ends. The arm is 3.0 inches long between socket centers and is finished with a Black Powder Coating. The side of the arm includes a tightening knob which allows you to open and close the socket ends. For a layout of the dimensions RAM-B-201 arm, take a closer look with the RAM-B-201 Design Drawings (pdf file).

Garmin GPS Mount Base Design:

The RAM-B-309-1 RAM Mount Powder Coated Marine Grade Aluminum Clutch/Brake Motorcycle Mount Base includes a 1 inch diameter Rubber Ball and a hexagonal openning for the connection of an optional secondary RAM-B-309-3 Rubber 1 inch diameter ball. Included with this base is both standard and metric mounting bolts.

The base connects to the left or right side of your handlebar clutch/brake reservoir on the Honda Goldwing and other select Motorcycles. To see if this base will work with your motorcycle, check the hole spacing of the base against your clutch/brake reservoir. The holes centers have a minimum width of 0.94 inches and a maximum of 1.58 inches and can be viewed in the design drawing below.

RAM E-Drawings and In Use Pictures:

To understand more about the RAM-B-309-1 Motorcycle Mount Base hole spacing and ball layout and location, check out the design drawing below. The second image shows the RAM-B-309-1 in use and how the base mounts to the clutch/brake reservoir.

RAM-B-309 Base e-drawing

RAM-B-309 Base In Use

RAM Motorcycle Mount Installation:

GARMIN NUVI 500 SERIES MOTORCYCLE BRAKE MOUNT PRODUCT FEATURES	Back to Top

Warranty: Manufacturer's Life Time Warranty. Cradle Design: Custom Cradle for Garmin nuvi 500 and 550 Series. Cradle Material: Black High Strength Composite Plastic. Mount Material: Black Powder Coated Marine Grade Aluminum. Mount Ball Size: RAM 1 inch Solid Rubber Ball. Pivot Point Design: RAM Patented 1 inch Rubber Ball and Socket Joint. Arm Type: RAM Arm with Dual 1 inch Sockets. Arm Length: Standard length of 3 inches between socket centers. Base Type: Motorcycle Brake/Clutch Reservoir Base Common Applications: Motorcycle Mounts: Used mostly with Goldwing and Harley Davidson Motorcycles.

GARMIN NUVI 500 SERIES MOTORCYCLE BRAKE MOUNT WHAT'S IN THE BOX?	Back to Top

1. RAM Mount Garmin nuvi 500 Series Cradle (RAM-HOL-GA32U) 2. RAM Mount Diamond Plate with 1 inch Ball (RAM-B-238U) 3. RAM Mount Standard Length Dual 1.0 inch Socket Arm (RAM-B-201U) 4. RAM Mount Motorcycle Handle Base with Single 1 inch Ball (RAM-B-309-1U)

GARMIN NUVI 500 SERIES MOTORCYCLE BRAKE MOUNT CUSTOMER REVIEWS	Back to Top
Click here to Add Your Own Review. (It's quick and easy! No login required.)
Réal's Review: Rating: Date: 2008-11-16 Easy to fit and to adjust for riding view. The GPS is secured as I wanted it.
